Used to measure the magnetic strip, magnetic nail and determine the direction of the sensor. It uses magnetoresistance or the Hall effect to detect changes in the magnetic field, and determines the navigation direction by measuring the strength and direction of the magnetic field. Magnetic navigation sensors are widely used in aerospace, logistics, vehicle navigation and other fields, which can help determine the position, speed and direction of objects. In mobile devices, magnetic navigation sensors can also be used to provide compass functionality and map navigation. They are an important part of the fixed orbit navigation system of mobile robot (AGV).

Positioning sensor(IPS Series)

Positioning sensor(IPS Series)

* Measurement range: 0~104mm
* Linear range: 1~103mm
* Distance between sensor and detection plate: Max 3mm
* Repetition accuracy: ±0.1mm
* Resolution: 104μm
* Analog output: 1*voltage output 0~10V/1*current output 4~20mA
* Load resistance: Current output: ≤400 Ω/Voltage output: ≥1000Ω
Selection of models
Line following sensor(MGS Series)

Line following sensor(MGS Series)

* Detection range: 160mm
* Detection accuracy: 1mm, 3mm
* Output response time:<5ms
* Sensitivity adjustment: 0~9
* interface：RS232、RS485、RS485-Modbus、CAN-HS、CANOPEN
* Detection medium: magnetic stripe, magnetic nail, etc
Selection of models
Magnetic Ruler(MLS Series)

Magnetic Ruler(MLS Series)

* Detection range: 160mm, 320mm, 480mm, 640mm
* Detection accuracy: 1mm
* Output response time:<5ms
* Sensitivity adjustment: 0~9
* Interface: RS232, CAN bus, switch output
* Detection medium: magnetic stripe, magnetic nail, etc
Selection of models
Magnetic Landmark (MDS Series)

Magnetic Landmark (MDS Series)

* Induction magnetic pole: S pole, N pole
* Output mode: S pole signal and N pole signal NPN open collector output, maximum current 100mA, with self-recovery fuse protection
* Detection distance: 10mm-50mm
* Output indication: LED light
* Response time: 2ms
* Protection class: IP-54
Selection of models

Solutions for your industry, ready for your choices
